Industralight ALT418 Inground LED Pathway

Industralight ALT418 is a high quality light sector fixture which is ideal for pathway lighting and landscape lighting applications. The fitting is construction from high pressure aluminium and powdercoated. The photometric performance is improved due to a convex tempered glass lens.

Electrical Parameters

Input Voltage100-240VAC
Max Power Consumption5W
LED Driver ClassificationIntegral LG-D LED Driver
Light Source ClassificationEpistar-T LED

Mechanical Specifications

Minimum IK RatingIK10
IP Protection RatingIP67
Overall Diameter210mm
Body Diameter197mm
Overall Depth130mm
Standard Colour/FinishBlack Powdercoat
Recommended Operating Temp  -20°C – +45°C

Configuration Options

  • Two directional version also available
  • Non standard colours available by special request
  • DALI dimmable LED driver available by request

Photometric Information

Typical Light Source Efficacy85lm/W
CCT Colour Temperatures3000K / 4000K / 6500K
Colour Rendering Indec [CRI]>80
Beam Angle/Viewing Angle60°

Detailed photometric report and IES files available by request

Lighting Design & Simulations

Industralight can provide independent LUX calculations and 3D lighting simulations for your project incorporating this product. Please contact our office for more information on design services.

Warranty Information

Industralight fixtures are manufactured to a high quality standard using finest quality LED components and materials. This product is covered by a full product replacement warranty.

Please see our warranty policy for full details.

Series Model NumberALT418
Specify Colour Temp3000K / 4000K / 6500K
  Specify Fitting ColourBlack
  Warranty InformationExtended Warranty Available
