Industralight CD400 Linear LED Wall Washer

Industralight CD400 is a professional linear luminaire designed for wall washing, grazing, building facades and other architectural lighting applications. The body is constructed from extruded aluminium and features a tempered glass lens. CD400 is available in several lengths and beam optic configurations.

Electrical Parameters

Input Voltage100-240VAC
Max Power Consumption27W / 54W
LED Driver ClassificationIntegral Constant Current
Light Source ClassificationCREE XPG2
Optional RGB ConfigurationRGB – 24VDC Only

Mechanical Specifications

Minimum IK RatingIK09
IP Protection RatingIP66
Profile Dimensions78x50mm
Nominal Lengths500mm / 1000mm
Construction MaterialAluminium & Tempered Glass
Recommended Operating Temp-20°C – 50°C

Configuration Options

  • Custom length by special request
  • DALI dimmable LED driver available by request

Photometric Information

Typical Light Source Efficacy100lm/W
CCT Colour Temperatures3000K / 4200K / 6500K / RGB
Colour Rendering Indec [CRI]>85
Beam Angle/Viewing Angle15° / 25° / 45°

Detailed photometric report and IES files available by request

Lighting Design & Simulations

Industralight can provide independent LUX calculations and 3D lighting simulations for your project incorporating this product. Please contact our office for more information on design services.

Warranty Information

Industralight fixtures are manufactured to a high quality standard using finest quality LED components and materials. This product is covered by a full product replacement warranty.

Please see our warranty policy for full details.

Series Model NumberCD400
Voltage24VDC or 240VAC
Specify Colour Temp3000K / 4200K / 6500K / RGB(24VDC)
Nominal Fixture Length500mm / 1000mm
Wattage27W / 54W
Warranty InformationExtended Warranty Available
