Industralight IL9220 Aero LED Washer

Industralight Aero fitting is a high powered LED washer fitting suited to indirect uplighting, architectural illumination of buildings, facade lighting, commercial wall grazing, and other exterior or interior lighting applications. Industralight Aero is avail­able in either 290mm or 510mm nominal lengths and features built in LED driver.

Electrical Parameters

Input Voltage100-240VAC
Max Power Consumption12W / 24W
LED Driver ClassificationIntegral Constant Current
Light Source ClassificationCREE XPE

Mechanical Specifications

Minimum IK RatingIK09
IP Protection RatingIP65
Nominal Dimensions135x65mm
Nominal Lengths290mm / 510mm
Standard Colour/FinishGraphite
Recommended Operating Temp-20°C – 50°C

Configuration Options

  • Non standard colours available by special request
  • DALI dimmable LED driver available by request

Photometric Information

Typical Light Source Efficacy90lm/W
CCT Colour Temperatures3000K / 4000K / 6000K
Colour Rendering Index [CRI]>80
Beam Angle/Viewing Angle30°

Detailed photometric report and IES files available by request

Lighting Design & Simulations

Industralight can provide independent LUX calculations and 3D lighting simulations for your project incorporating this product. Please contact our office for more information on design services.

Warranty Information

Industralight fixtures are manufactured to a high quality standard using finest quality LED components and materials. This product is covered by a full product replacement warranty.

Please see our warranty policy for full details.

Series Model NumberIL9220 Aero
Specify Colour Temp3000K / 4000K / 6000K
Specify Length/Size290mm / 510mm
Specify Wattage12W / 24W
Warranty InformationExtended Warranty Available
