Industralight DL86 Zhaga Series Commercial Architectural LED Downlight.
Industralight Zhaga series is a high-end commercial style LED downlight series that can be used for high end interior projects. The fixtures incorporate high performance Zhaga LED modules and are available in a wide range of beam angle options and other configuration options. Typical applications include commercial spaces, galleries, museums, hospitality, offices, airports, retail shopping centres etc.
Electrical Parameters
| Driver Input Voltage: | 90-260VAC |
| Power Consumption: | 24W / 35W / 60W |
| LED Driver Classification: | Constant Current |
| Light Source Classification: | CREE® Zhaga LED Module |
Mechanical Specifications
| Minimum IK Rating: | IK05 |
| IP Protection Rating: | IP20 |
| Fixture Material: | Aluminium Construction |
| Colour Finish: | White Trim + Silver Reflector |
| Fixture Style: | Wall Washer Adjustable |
| Trim Diameter: | 258mm |
| Ceiling Cutout: | 236mm |
Configuration Options
- Non standard trim colours available by special request
- DALI dimmable LED driver available by request
Photometric Information
| Typical Lumen Efficacy: | 110lm/W |
| CCT Colour Temperatures: | 3200K/4200K/6500K |
| Colour Rendering Index (CRI): | >80 |
| Beam Angle/Viewing Angle: | Various |
Detailed photometric report and IES files available by request
Lighting Design & Simulations
Industralight can provide independent LUX calculations and 3D lighting simulations for your project incorporating this product. Please contact our office for more information on design services.
Warranty Information
Industralight fixtures are manufactured to a high quality standard using finest quality LED components and materials. This product is covered by a full product replacement warranty. Please see our warranty policy for full details.
