Industralight RDL1431 IP67 26W Recessed LED Downlight

Industralight RDL1431 LED downlights feature high integrity IP67 rating which makes them suitable for demanding commercial industrial environments. The fixtures have a 316 marine-grade stainless steel trim and integral control gear.

Electrical Parameters

Input Voltage:100-240VAC
Power Consumption:26W
LED Driver Classification:Integral Constant Current
Light Source Classification:CXA-2520 LED


Mechanical Specifications

Minimum IK Rating:IK07
IP Protection Rating:IP67
Nominal Diameter:278mm Trim
Glass Lens Type:12mm Tempered Glass Lens
Material/Construction:Alloy & Stainless Steel Trim
Recommended Ambient Temp:-20°C – 45°C


Configuration Options

  • Can be finished in black or silver
  • Non-standard colour finishes available by special request
  • Dimmable LED driver can be factory fitted by special request
  • Wire suspension support harness included


Photometric Information

Typical Lumen Efficacy:110lm/W
CCT Colour Temperatures:3200K/4200K/5000K/6500K
Colour Rendering Index (CRI):>75
Viewing Angle:75°

Detailed photometric report and IES files available by request

Lighting Design & Simulations

Industralight can provide independent LUX calculations and 3D lighting simulations for your project incorporating this product. Please contact our office for more information on design services.

Warranty Information

Industralight fixtures are manufactured to a high quality standard using finest quality LED components and materials. This product is covered by a full product replacement warranty.  Please see our warranty policy for full details.

Series Model Number:RDL1431
Specify Colour Temp:3200K/4200K/5000K/6500K
Support Harness:Included
Specify Trim Colour:Black or Silver
Optional Dimmable:Factory-Fitted by Request

All product specifications are subject to change without notice. Industralight assumes no responsibility of errors or omissions. Please confirm product details prior to ordering.
