Industralight LGS200 LED Landscape Spotlight

Industralight LGS200 is a commercial grade luminaire designed for illumination of gardens, trees, and other landscape feature. LGS200 is manufactured from extruded aluminium with high corrosion resistance. The illumination performance is enhanced by the polished aluminium reflector and powerful integrated LED light source. Several accessories are available for LGS200 to suit specific mounting configurations.

Electrical Parameters

Input Voltage100-240VAC
Max Power Consumption30W / 45W
LED Driver ClassificationIntegral Constant Current
Light Source ClassificationCREE CXA2520

Mechanical Specifications

Minimum IK RatingIK09
IP Protection RatingIP65
Nominal Body Length195mm
Body Diameter150mm
Construction MaterialExtruded Aluminium
Standard Colour/FinishCorrosion Resistant Surface Treatment
Recommended Operating Temp-15°C – 45°C

Configuration Options

  • Several mounting accessories available by request
  • Non standard colours available by special request
  • DALI dimmable LED driver available by request

Photometric Information

Typical Light Source Efficacy100lm/W
CCT Colour Temperatures3000K / 4000K / 5000K
Colour Rendering Index [CRI]>80
Beam Angle/Viewing Angle15° / 24° / 36°

Detailed photometric report and IES files available by request

Lighting Design & Simulations

Industralight can provide independent LUX calculations and 3D lighting simulations for your project incorporating this product. Please contact our office for more information on design services.

Warranty Information

Industralight fixtures are manufactured to a high quality standard using finest quality LED components and materials. This product is covered by a full product replacement warranty.

Please see our warranty policy for full details.

Series Model NumberLGS200
Specify Colour Temp3000K / 4000K / 5000K
Specify Fixture ColourSilver / Black
Included Mounting AccessoriesGarden Spike
Optional Mounting AccessoriesMounting Base/300 Extension Pole/Glare Shield
Warranty InformationExtended Warranty Available
