Industralight Rebel® LED Floodlight Series 500W/600W

Industralight Rebel® series is a family of high quality LED floodlight fixtures which can be used for a variety of commercial and industrial lighting applications. Industralight Rebel LED floodlights are supplied integral LED driver and multi-purpose adjustable trunnion bracket. Typical applications include billboards & signage, area floodlighting, pole lighting, container and shipyards, industrial sites, warehousing, streetlighting, security lighting and more.

Electrical Parameters

Input Voltage:90-305VAC
Power Consumption:500W / 600W
LED Driver Classification:Meanwell HLG Series
Light Source Classification:Luxeon® ES LED

Mechanical Specifications

Minimum IK Rating:IK08
IP Protection Rating:IP65
Adjustable Mounting Bracket:180° Adjustable Trunnion Bracket
Material/Construction:Toughened Alloy Construction
Nominal Dimensions:811x606x369mm
Recommended Ambient Temp:-40°C – 50°C

Configuration Options

  • Adjustable mounting bracket included
  • Available in non standard colours by special request
  • 24VDC version available by special request

Photometric Information

Typical Lumen Efficacy:110lm/W
CCT Colour Temperatures:3200K/4200K/5000K/6500K
Colour Rendering Index (CRI):>70
Beam Angle/Viewing Angle:15° / 30° / 85° / 135°x85°

Detailed photometric report and IES files available by request

Lighting Design & Simulations

Industralight can provide independent LUX calculations and 3D lighting simulations for your project incorporating this product. Please contact our office for more information on design services.

Warranty Information

Industralight fixtures are manufactured to a high quality standard using finest quality LED components and materials. This product is covered by a full product replacement warranty.  Please see our warranty policy for full details.

Series Model Number:RF6500 / RF6600
Specify Wattage500W / 600W
Specify Colour Temp:3200K/4200K/5000K/6500K
Specify Voltage Type90-305VAC or 24VDC
Specify Colour:Black
Specify Beam Angle:15° / 30° / 85° / 135°x85°
