Industralight Rebel® 800 Modular LED Floodlight
Industralight Rebel® 800 is an industrial LED floodlight system which can be used for a variety of industrial lighting applications. Rebel LED floodlights are supplied integrated LED driver and multi-purpose adjustable trunnion bracket. Typical applications include billboards & signage, area floodlighting, pole lighting, container and shipyards, industrial sites, warehousing, streetlighting, security lighting and more.
Electrical Parameters
| Input Voltage | 90-305VAC |
| Max Power Consumption | 800W |
| LED Driver Classification | Meanwell |
| Light Source Classification | Rebel LED |
Mechanical Specifications
| Minimum IK Rating | IK10 |
| IP Protection Rating | IP65 |
| Nominal Dimensions | 743x724x229mm |
| Construction Material | Toughened Aluminium |
| Standard Colour/Finish | Black / Corrosion Resistant |
| Recommended Operating Temp | -40°C – 50°C |
Configuration Options
- Several beam angle / optics available
- Non standard colours available by special request
- DALI dimmable LED driver available by request
Photometric Information
| Typical Light Source Efficacy | 110lm/W |
| CCT Colour Temperatures | 3000K / 4000K / 5000K / 5700K |
| Colour Rendering Index [CRI] | >80 |
| Beam Angle/Viewing Angle | 10° / 15° / 30° / 90° |
| Optional Configuration | Several Asymmetrical Options Available |
Detailed photometric report and IES files available by request
Lighting Design & Simulations
Industralight can provide independent LUX calculations and 3D lighting simulations for your project incorporating this product. Please contact our office for more information on design services.
Warranty Information
Industralight fixtures are manufactured to a high quality standard using finest quality LED components and materials. This product is covered by a full product replacement warranty.
Please see our warranty policy for full details.
