Industralight TWL501 IP65 LED Wall Light

Industralight TWL501 is an external LED wall light with high-quality LED light source components, The fitting is constructed from extruded aluminium and features corrosion resistant powdercoated surface treatment. TWL501 is suited to commercial and residential projects where a high quality architectural design is preferred.

Electrical Parameters

Input Voltage100-240VAC
Max Power Consumption13W
LED Driver ClassificationHEP Integral Constant Current
Light Source ClassificationSharp Zenigata COB LED

Mechanical Specifications

Minimum IK RatingIK09
IP Protection RatingIP65
Overall Height155mm
Body Diameter80mm
Overall Projection From Wall116mm
Construction MaterialAluminium
Standard Colour/FinishBlack / White / Silver
Recommended Operating Temp-15°C – 55°C

Configuration Options

  • Non standard colours available by special request
  • Remote mounted DALI dimmable LED driver available by special request

Photometric Information

Typical Light Source Efficacy115lm/W
CCT Colour Temperatures3000K / 4000K / 6000K
Colour Rendering Index [CRI]>85
Beam Angle / Viewing Angle10° / 30° / 55°

Detailed photometric report and IES files available by request

Lighting Design & Simulations

Industralight can provide independent LUX calculations and 3D lighting simulations for your project incorporating this product. Please contact our office for more information on design services.

Warranty Information

Industralight fixtures are manufactured to a high quality standard using finest quality LED components and materials. This product is covered by a full product replacement warranty.

Please see our warranty policy for full details.

Series Model NumberTWL501
Specify Colour Temp3000K / 4000K / 6000K
Specify Fixture ColourBlack / White / Other
Specify Beam Angle10° / 30° / 55°
Warranty InformationExtended Warranty Available
